The cabinet is already assembled and adjusted, but the facades were decided to be decorated: what to recalculate before ordering four carved wooden overlays N-475 at 0.6 kg each

The cabinet is already ready: four hinged fronts are hung, hinges are adjusted, gaps are even, handles are in place. After that, the designer decides to add one carved wooden overlay N-475 to each door.

One N-475 has a confirmed weight of 0.6 kg. This means the entire cabinet will become 2.4 kg heavier after installing four pieces. But technically, you need to check not "whether the cabinet will hold another 2.4 kg," but each door individually: its own weight will increase by 0.6 kg, and the impact on the hinge system will also depend on where exactly on the front the overlay is placed.

Therefore, the correct sequence is as follows: make four full-size templates 350×180 mm → check handles and adjacent doors → determine the exact center of each N-475 → find out the model and permissible parameters of existing hinges → recalculate the mass of each door → agree on installation on the actual surface → only then order four overlays.

Neither the number of hinges nor the permissible load can be assigned "based on experience" without the passport of the specific hardware. The article helps prepare data with which a furniture maker or hinge manufacturer can give a proper technical answer.

Go to Catalog

Carved wooden overlay N-475 350×180×16 mm: what actually gets added to the facade

N-475 is a large rectangular carved overlay made of solid beech or oak. The product card confirms:

Parameter	N-475
Size A × B × C	350 × 180 × 16 mm
Mass	0.6 kg
Material	Beech / Oak
Sanding	Standard / Prestige
Regluing quality	the card offers preparation for subsequent finishing
Made to order	5–10 days
Minimum order	From 1 pcs.
Beech, Standard	5,260 RUB as of 08.09.2026
Oak, Standard	6,500 RUB as of 08.09.2026

The oak Standard was shown in stock in Saint Petersburg at the time of checking in the quantity of 3 pcs.; the remaining stock needs to be re-checked before ordering.

If the product has already been selected by design, buy carved wooden overlay N-475 is after a technical check of the facade. The size 350×180 mm determines the geometry of the decor, and 0.6 kg determines the change in the mass of the movable door.

Four N-475 units add +2.4 kg to the cabinet, but only +0.6 kg to each door leaf

For four identical facades with one overlay on each:

4 × 0.6 = 2.4 kg.

This is the total additional mass of the entire decor set.

But if the cabinet has four independent hinged doors, each hinge system receives not 2.4 kg of additional mass, but a load associated with one N-475 on its own leaf.

Working table:

Facade	Mass before decor	N-475	Mass after
Door 1	M1	+0.6 kg	M1 + 0,6
Door 2	M2	+0.6 kg	M2 + 0,6
Door 3	M3	+0.6 kg	M3 + 0,6
Door 4	M4	+0.6 kg	M4 + 0,6

Exactly the values M1+0,6, M2+0,6 and then need to be compared with the documentation of the installed hardware.

You cannot write:

"four overlays weigh only 2.4 kg, so the hinges will definitely hold."

This mixes four independent door assemblies into one number.

Our factory also produces:

View Full Product Catalog

How noticeable is +0.6 kg: the percentage depends on the initial weight of the door

The number 0.6 kg itself says nothing without the weight of the facade.

Example just to understand the scale:

Door weight before N-475	After installation	Weight increase
6 kg	6.6 kg	10%
8 kg	8.6 kg	7,5%
10 kg	10.6 kg	6%
12 kg	12.6 kg	5%

These figures are not permissible hinge loads. They show why the same N-475 affects two different facades differently.

If the door is already close to the limits of the selected hardware even without decoration, an increase of 0.6 kg can become significant. If the hinge system has a large confirmed margin, the conclusion will be different.

Therefore, the first number after the mass of N-475 should be the current mass of the specific door leaf.

Wooden decor for furniture can be purchased right away — hinges are first checked against the specification sheet.

For a technical check, a furniture maker needs more than just "four overlays."

Pass on:

• height and width of each door;
• facade thickness;
• facade material;
• actual or calculated weight of the door;
• number of hinges;
• the exact hinge model;
• photo of hardware marking;
• method of attaching the hinge to the body and facade;
• current adjustment state;
• position of center N-475 on the door.

After this, a table or manufacturer's catalog of hinges opens.

For different systems, allowable ranges depend not only on mass, but also on door dimensions, number of attachment points, installation scheme, and other parameters.

Therefore, the request Buy wooden furniture decor must end with a check of the existing furniture unit if decor is added after assembly.

Position N-475 is important: 0.6 kg closer to the hinges and at the outer edge are not the same thing.

Additional mass creates load not only by its weight but also by its distance from the hinge line.

For a simplified assessment, you can look at the static moment:

M = m × g × r,

where m — mass of the overlay, g — acceleration due to gravity, r — horizontal distance from the hinge line to the center of mass of N-475.

For 0.6 kg:

0.6 × 9.81 ≈ 5.89 N of weight.

If the center of the overlay is approximately 200 mm from the hinge line:

5.89 × 0.20 ≈ 1.18 N·m.

If approximately 400 mm:

5.89 × 0.40 ≈ 2.35 N·m.

That is, when the distance doubles, this simplified moment also doubles.

This is not a calculation of the acceptability of specific hinges and not a basis for assigning their number. The actual load distribution depends on the height of the door leaf, the distance between hinges, fasteners, the rigidity of the facade, and the design of the hardware.

But the example explains why the cabinet maker needs to show not only the mass of 0.6 kg, but also the exact coordinate N-475 on the facade.

Four paper templates 350×180 mm are more useful than one

A common mistake is to cut out one rectangle 350×180 mm, attach it to one door, and decide that the composition is approved.

For four facades, four templates are needed simultaneously.

They will show:

• the overall rhythm;
• uniformity of heights;
• the distance between overlays on the central doors;
• the connection with handles;
• possible collision of decor when opening;
• how large do 350 mm look on each facade;
• doesn't four identical elements turn into too dense a composition.

For example, on a facade 500 mm wide, a centered N-475 nominally leaves:

(500 − 350) ÷ 2 = 75 mm on each side.

On a door 450 mm:

(450 − 350) ÷ 2 = 50 mm.

At a width of 400 mm:

25 mm.

These numbers don't tell whether it's beautiful or not, but they quickly show how much free space actually remains.

The decorative overlay cannot be calculated separately from the handle

N-475 has a thickness of 16 mm and a noticeable carved relief. Therefore, it's important to check not only the 350×180 rectangle, but also the working area for the hand.

On each facade, mark:

• the center of the handle;
• the actual grip point;
• the finger trajectory;
• the edge of the rosette or handle base;
• the distance to N-475;
• the position of the adjacent door when opening.

If the handle is directly in the ornament area, there are three proper solutions: change the decor position, modify the handle per the design, or choose a different overlay.

A bad option is to order N-475 and then "trim it a little to fit the handle."

Decorative wooden furniture overlays: why N-475 should not be trimmed after purchase

N-475 is a complete carved ornament.

Trimming the edge may:

• disrupt symmetry;
• remove part of a leaf or curl;
• expose the end grain of the wood;
• change the distribution of visual mass;
• require additional manual refinement and finishing.

If the 350×180 rectangle does not fit on the facade due to a handle, panel, or frame, it is better to return to the the category of decorative overlays and find the smaller element.

This is especially logical because the STAVROS section currently has hundreds of models of different sizes and shapes.

Four fronts: checking the collision of adjacent N-475 when opening

On a closed cabinet, the two central overlays may look perfect.

But when opening, the doors change their relative position.

Check:

• how much N-475 protrudes in thickness;
• whether there is decor on the adjacent door;
• how the inner edges of the panels diverge;
• whether the reliefs meet at the start of movement;
• whether the overlay touches the cabinet body or the adjacent handle.

The simplest way before purchase is to glue four cardboard templates 16 mm thick or make lightweight 3D mockups.

A flat paper sheet shows the area but does not show the protrusion.

The mass of the decor cannot be added to "one hinge"

Phrase:

"the overlay weighs 0.6 kg, so the top hinge will receive another 0.3 kg, the bottom — 0.3 kg"

is incorrect as a universal model.

The distribution of forces between hinges is not reduced to simply dividing the mass in half. The top and bottom points perceive different components of forces, and with three or four hinges, the picture depends on the position of each, the rigidity of the system, and adjustment.

Therefore, the article deliberately does not provide a formula for "how many kg per hinge."

Documentation from the manufacturer of the specific hardware is needed.

What to do if the hinge model is unknown

Do not immediately order four N-475 with the thought "we will figure it out later."

Try to find:

1. logo or marking on the hinge cup;
2. a code on the arm;
3. marking on the strike plate;
4. the old furniture order;
5. cabinet manufacturer's specification.

Take clear photos of the hinge in both closed and open positions.

If the model cannot be identified, a furniture maker can assess the need to replace the entire hinge system with a known and documented one.

But you cannot choose new hardware based only on the article number: the dimensions and weight of the specific front panel are needed.

How to find out the weight of an already installed door if it is not in the old specification

The mass of the facade of a finished cabinet is often not recorded anywhere. Then there is no need to guess it by area and material if the exact result is important for checking hinges.

There are several reliable sources of data.

The first is the old specification from the furniture manufacturer. It may include the facade dimensions, material, thickness, glass, profile, handle, and hardware model. Based on this data, the manufacturer can restore the mass more accurately than a buyer can from a photo.

The second is the documentation for the facade itself, if the doors were ordered separately.

The third is actual weighing of the removed door by a furniture maker. Removing an already adjusted door just for a home experiment without understanding the construction is not advisable: after reinstallation, adjustment may be required, and a heavy facade can easily be damaged.

If the exact weight is not available, it is still useful to inform the furniture maker about:

• dimensions;
• the material;
• thickness;
• the presence of glass or a mirror;
• frame profile;
• the handle;
• additional overlays that are already installed.

But the final conclusion "the hinges are suitable" should be made by a specialist based on real data, not on the approximate mass from the article.

Four identical facades visually may have different initial weights

The cabinet looks symmetrical, and it seems natural to check the first door once and apply the result to the other three.

This is only acceptable if the doors are truly identical in construction.

In practice, they may differ:

• handles;
• internal mirror inserts;
• decorative frames;
• hinges from different series after repair;
• number of hinges;
• door closers;
• additional internal elements.

Therefore, before ordering N-475, it is better to fill in four separate lines.

Facade	Size	Weight up to N-475	Loops	Additional elements	New weight
F1	___	___	___	___	+0.6 kg
F2	___	___	___	___	+0.6 kg
F3	___	___	___	___	+0.6 kg
F4	___	___	___	___	+0.6 kg

If after filling it turns out that F1–F4 are indeed identical, great — the check reduces to one type of node. But this is already a confirmed sameness, not an assumption.

The center of N-475 should be written as a number, not as the words "approximately in the middle"

After approving four templates, it is better to transfer the position of each overlay to the assembly sheet using coordinates.

For a facade with a width of W and height H when geometrically centering a rectangle N-475 350×180 mm:

X = W ÷ 2;

Y = H ÷ 2.

But this is only the starting point. The handle, frame, panel, or adjacent decor may require an offset.

If the designer shifts N-475, the new position should be recorded, for example:

center of N-475: X=250 mm from the hinge edge, Y=420 mm from the bottom edge.

This way, the cabinetmaker gets a measurable parameter and can assess the location of the additional mass relative to the hinge line.

The phrase "overlay closer to the handle" is almost useless for technical verification.

If the hinge passport is not found: this is not a reason to test the load experimentally

Bad scenario:

we'll glue one N-475, watch for a week, and see if the door sags or not.

The absence of visible sagging in the first days does not prove the acceptability of the joint.

If the model of the old hinges could not be identified, normal options are as follows:

• request data from the cabinet manufacturer;
• invite a furniture maker for identification;
• replace the hardware with a known system with documented parameters;
• refuse the heavy overlay and choose a lighter decor.

The "let's see if it holds" experiment is especially bad on expensive facades: consequences appear only after gluing and finishing N-475, when returning the door to its original state is more difficult.

Beech or oak N-475: first finishing, then ordering four parts

If the ornament will be fully painted with opaque enamel, preparation for enamel can be considered.

If the wood texture must remain visible, a configuration designed for translucent finishing is needed.

STAVROS describes "Under enamel" as a blank without special selection of lamellas by color and texture, intended for dense tinting and painting with enamels. "Under tinting" implies selection of wood by color and texture and is intended for translucent finishing.

Details can be checked on the page beech under enamel and oak under tinting.

For four facades, it is better to fix the same material, sanding quality, and finish, unless the designer intended otherwise.

How much do four N-475 cost in Standard

At the time of checking:

beech Standard — 5,260 ₽/pc.;

oak Standard — 6,500 ₽/pc.

A batch of four beech ones:

4 × 5 260 = 21 040 ₽.

Oak ones:

4 × 6 500 = 26 000 ₽.

The difference:

26 000 − 21 040 = 4 960 ₽.

This is the cost of the overlays themselves before delivery, finishing, and installation work.

The price changes, so before payment it needs to be verified in the product card.

Buying wooden decor for furniture and choosing glue are two different checks.

A finished cabinet has two independent technical questions.

First: whether the door and its hinge system can withstand the new weight and position of the decor.

Second: how N-475 is attached to a specific facade surface.

One cannot reason:

"if strong glue holds 0.6 kg, then everything is safe."

The glue is responsible for bonding the overlay to the door.

Hinges hold and move the entire door together with the new overlay.

Both checks must end successfully.

Mounting adhesive next to N-475: what STAVROS confirms

In STAVROS's advice for large wooden decor, there is a division based on surface conditions.

For unpainted wooden decor on an unpainted surface, the table indicates PVA Kleiberit 303.0 D3.

For large primed or painted decor / painted surface, Tytan Professional Classic Fix is specified.

Therefore assembly glue for wooden decor cannot be automatically assigned to any door without checking its coating and the instructions of the composition itself.

Before installation, determine:

• what the facade is made of;
• how it is painted;
• what N-475 is coated with;
• whether degreasing or other preparation is required;
• whether the finish allows adhesive bonding.

How to glue N-475: do not invent your own technology

Official STAVROS advice for large decor describes the sequence: mark the position, apply suitable adhesive, attach the element, if necessary hold the compound according to instructions, then finally press firmly.

The full current technology is best viewed on the page how to glue wooden decor.

In this article, a different sequence is more important:

hinges → template → position → coating → glue → installation.

If you skip the first stages, perfect gluing will not fix an overloaded or conflicting door.

Order four N-475 with one specification

Order line:

N-475 / 350×180×16 mm / beech or oak / Standard or Prestige / quality of re-gluing for the chosen finish / 4 pcs.

Separate mounting sheet:

Facade	Overlay	Center X	Center Y	Weight +	Hinges checked
1	N-475	___	___	0.6 kg	Yes / no
2	N-475	___	___	0.6 kg	Yes / no
3	N-475	___	___	0.6 kg	Yes / no
4	N-475	___	___	0.6 kg	Yes / no

So four identical decorative items turn into four verified furniture units.

What to send to the furniture maker before purchasing N-475

Minimum package:

• photo of the entire cabinet;
• photo of each door;
• facade dimensions;
• thickness;
• facade material;
• weight of each leaf or data for its calculation;
• model and number of hinges;
• photo of the hinge marking;
• handle placement;
• four templates N-475 350×180;
• assumed centers;
• overlay mass 0.6 kg;
• selected finish.

If the cabinet is made by a third-party company, it makes sense to send the same package to the furniture manufacturer or hardware supplier.

When it's better not to buy N-475 yet

Postpone the order if:

• hinge model is unknown;
• facades are already sagging;
• hinges regularly require adjustment;
• no data on allowable sizes and weight of the door;
• N-475 conflicts with the handle;
• two adjacent overlays may meet when opening;
• there is no free field 350×180 mm on the door;
• the ornament is planned to be trimmed;
• the mounting method on the current surface is not defined;
• the material and future finish have not been chosen yet.

In these cases, the alternative is not necessarily to abandon the decor. You can choose a smaller or lighter element from the category.

Buy furniture decor: when N-475 does not fit a specific cabinet

N-475 is not a universal overlay for any door.

If the template shows a conflict, it is better buy furniture decor from the general category and choose a different width, height, thickness, or shape.

This is more useful than forcing one ornament to work where it interferes with the handle, frame, or opening.

Main conclusion:

Four N-475 add 2.4 kg to the cabinet in total, but technically four separate panels are checked — +0.6 kg each.

After checking the weight, hinge system, decor position, and mounting base, you can order four identical overlays as a single purchase.

Questions before ordering N-475

What is the size of N-475?

350 × 180 × 16 mm.

How much does one overlay weigh?

0.6 kg.

How much do four N-475 weigh?

2.4 kg.

Does each door leaf get an additional 2.4 kg?

No. If each of the four doors has one overlay installed, each leaf gets +0.6 kg.

Can you simply add a third hinge?

You cannot give a universal answer. The decision is made based on the documentation of the specific hinge system and the cabinet front parameters.

Does the N-475 position affect the load?

Yes. The farther the additional mass is from the hinge line, the greater the static moment it creates. Specific acceptability is checked against the hardware.

Do you need to know the mass of the door leaf itself?

Yes. After installation, the new mass is compared M + 0.6 kg with the system's permissible parameters.

Can I try on only one overlay?

For a cabinet with four fronts, it's better to use four full-size templates simultaneously.

What to do if N-475 interferes with the handle?

Change the design position, the handle, or choose a different overlay. Trimming the ornament "in place" is a bad scenario.

Is there N-475 in beech and oak?

Yes.

Are Standard and Prestige available?

Yes.

How much does beech Standard cost?

5,260 RUB as of September 8, 2026.

How much does oak Standard cost?

6,500 RUB as of the time of verification.

Which glue should I use?

Depends on the material and surface condition. For painted/primed large STAVROS elements, Tytan Professional Classic Fix is indicated; for unpainted solid wood on an unpainted base, the official table specifies PVA Kleiberit 303.0 D3.

Can good glue be considered proof that the hinges will hold?

No. These are two independent components.

What should be checked last before payment?

Weight of each door after +0.6 kg, hinge model, N-475 position, four templates, handles, adjacent doors, material, sanding, finish, and mounting method.
